Slat Expander Rolls
Aluminum Slat expanders are used for wrinkle removing on coating
machines which is available in any length and standard diameter
6”. Bigger diameter can be made as per specific requirements.
Normally plain surface is provided but some applications
serration is required on surface for gripping. While ordering
should provide the application temperature, web material, plain
or serration required on surface, maximum speed of web material
to meet all your requirements. For soundless working the rolls
are also available with ball bearing type cam mechanism also.
Normal expansion is 25mm.
Slat Expander Roll are available in wooden slat with felt covering and With aluminum slats available in 6” diameter 8”diameter & 12” diameter in any working width. Particularly suitable for slow speed machines like coating cloth coating machines, Flat Bed Printing machine, artificial leather cloth before Batching machine etc. The Roll is fitted with cam mechanism fitted with on bearings with left & Right slats from center. For longer width three slats are fitted and middle slats are fixed to avoid V shaped wrinkle-removing action. Available with foot mounting pedestals.
 |
 |
